Microwave Radar Sensor Switch Module Human Body Induction Switch Module Intelligent Sensor (RCWL-0516)

Product Introduction
RCWL-0516 microwave induction module is an automatic induction control module using Doppler radar technology. It has high sensitivity, long sensing distance, high reliability, large sensing angle and wide power supply range etc. It can be applied to a variety of human body induction lighting occasions, anti-theft alarm occasions.

Product Features
★Low power consumption: working current is about 2.36mA
★Wide working voltage：4V-28V
★High sensitivity; sensing distance is far and adjustable：1CM-7M
★With penetration detection, it can penetrate the insulator.

Application Field
★Induction lighting
★Remote Sensor Switch（Control relay; triode switch）
★Alarm induction detection

Attention
1、The front of the RCWL-0516 sensor board has a strong sensing effect, and there is no metal barrier in front of it.
2、RCWL-0516 sensor board surface and mounting carrier surface should reserve more than 1CM space, and parallel to the mounting carrier.
3、Avoid strong magnetic filed changes or where the conductor moves (such as fans)
4、The power supply must use a clean and stable power supply, you can add 47pf capacitor to the power input VIN to prevent interference
5、The microwave module cannot be largely used in the same area. Each module is separated by at least 1M or more, otherwise it will affect each other.
